Power converter design platform · SiC & GaN

From spec to switching loss, before you build.

Pick a topology, enter your specs, and Simivolt designs the converter. Conduction loss comes from closed-form expressions. Switching loss is simulated from the device, the gate driver and your layout parasitics, because that is where estimates go wrong.

Datasheet-based models for SiC MOSFETs and GaN HEMTs.

Converter DesignerPlaceholder values
BuckBoostTotem-pole PFC3-level inverter
Vin
230 Vac
Vout
400 V
Pout
3.3 kW
fsw
65 kHz
Loss per device at full load (W)SiC fast leg, Si slow leg
  • Q1 fast leg14.9
  • Q2 fast leg14.9
  • S3 slow leg4.0
  • S4 slow leg4.0
Conduction (closed-form)Turn-on (simulated)Turn-off (simulated)
Total semiconductor loss
37.8 W
Switching share
53%
Semiconductor efficiency
98.87%
Workflow

One flow,
from requirements to losses

Top-down design: you start from what the converter must do, not from a datasheet.

01

Choose a topology

Buck, boost, PFC, totem-pole PFC, three-level inverter.

02

Enter specs

Input and output voltage, power, switching frequency, ripple targets.

03

Pick devices and gate drive

From the curated SiC and GaN library, with gate resistance and drive voltages.

04
PulseIQ engine

Analyse

Conduction loss from closed-form expressions; switching loss simulated transition by transition.

05

Review and export

Loss breakdown, waveforms and operating points, exported as CSV.

Topologies

Start from the
converter you are building

Each topology comes with its own spec form, operating-point equations and device stress calculations.

DC–DC · Non-isolatedSupported

Buck

48 V to point-of-load conversion, where GaN at high frequency makes switching loss dominant.

DC–DC · Non-isolatedSupported

Boost

PV and battery front ends; hard-switched SiC turn-on is where the budget goes.

AC–DC · PFCSupported

Boost PFC

Classic CCM front end. Losses are evaluated across the line cycle, not at one point.

AC–DC · Bridgeless PFCSupported

Totem-pole PFC

High-efficiency front end for server PSUs and EV chargers, with fast and slow legs analysed separately.

DC–AC · MultilevelSupported

Three-level inverter

800 V drives and PV inverters, with lower device stress and per-switch losses for outer and inner devices.

NextComing soon

Need another topology?

Tell us what you are designing. Requests decide what we add next.

Request a topology
Modules

Two modules today.
A full design suite next.

One account, one workspace. Each module works on its own and feeds the next.

LiveModule 01

Converter Designer

Enter the spec, get the converter. Operating point, device voltage and current stresses, conduction and switching loss per device, and efficiency across load.

  • Spec-driven forms for each topology
  • Peak, RMS and average device stresses
  • Loss breakdown by device and mechanism
See Converter Designer
LiveModule 02 · The engine

PulseIQ Switching Loss

The switching-loss engine inside Converter Designer, also usable on its own. Datasheet in, switching behaviour out, across current, gate resistance and bus voltage.

  • Eon, Eoff, transition times, dv/dt and di/dt
  • Overcurrent and overvoltage vs load current
  • Suggested parasitics from package and layout
See how PulseIQ works
On the roadmap

Magnetics

Inductor and transformer design, linked to your converter operating point.

Notify me
On the roadmap

Thermal and heatsink

Junction temperature and heatsink sizing from the computed losses.

Notify me
Why simulate

Conduction loss is a formula.
Switching loss is not.

Conduction loss follows from RMS current and on-resistance. Switching loss is decided in a few nanoseconds by how the device, the gate driver and the layout interact.

Linear-ramp estimates ignore nonlinear capacitances, common-source inductance and the driver's output stage. PulseIQ simulates the transition from datasheet-fitted device models, so the number you budget is the number you measure.

Device

Transfer curve, Ciss, Coss, Crss vs Vds, Rds(on)

Gate driver

Rg,on and Rg,off, drive voltages, source and sink current

Parasitics

Power-loop and common-source inductance

PulseIQ transition simulation

Solved across load current, bus voltage and gate resistance

  • Eon
  • Eoff
  • dv/dt
  • di/dt
  • Vds overshoot
  • Id overshoot
  • t_rise, t_fall
Applications

Built for Every
Power Conversion Domain

From electric vehicles to data centres, PulseIQ accelerates switching analysis wherever wide-bandgap devices are used.

⚡

Electric Vehicle Power Converters

Optimise switching losses for EV inverters and on-board chargers operating at high dv/dt.

☀

Renewable Energy Inverters

Evaluate SiC performance in solar and wind inverters for maximum efficiency at grid frequencies.

◉

Motor Drive Systems

Characterise switching behaviour across the full torque-speed range for industrial motor drives.

⟲

High-Frequency DC-DC Converters

Analyse GaN switching at MHz frequencies for compact, high-density power supplies.

◈

Wide-Bandgap Device Evaluation

Benchmark and compare SiC and GaN devices for new design selection without lab measurements.

▦

Data Centre Power Supplies

Meet stringent efficiency targets for 48V server power delivery using accurate loss prediction.

Stay in the loop

Get Simivolt news: new devices in the library, new topologies and modules (magnetics, thermal and heatsink) and release notes. Just the updates, in your inbox.

We'll only use your address for Simivolt updates.

See PulseIQ on your own devices

Tell us about your project and we will set up a walkthrough with the SiC or GaN parts you are evaluating.

Contact

Ready to Accelerate
Your Power Design?

Get in touch with the team at Simivolt Dynamics and access PulseIQ for your next power converter project.

Or email directly: sales@simivoltdynamics.com
